Brand: Zhongcheng
Model: GZD-850*3000
Price: CNY 80000 / set
Min. Order: 1 set
vibrating feeder
feeding machine
shaking feeder
The series machine belongs to line vibrating feeder.It has these merits :stable vibration,reliabe work ,long service time,etc.It can send various materials into the crusher uniformly, continuously,also separate the raw materials primarily.It is widely used in metallurgy,coal ore,building materials, and is the united crushing and screening equipment in silicate and chemical industries.
Technical Parameters:
Type GZD-600x1600 GZD-960x3600 GZD-1100x3800 GZD-12002400x GZD-1300X4900 GZD-1500X6000
Max.Feeding Size 200 500 580 580 580 650 800
Handling Capacity(t/h) ~80 ~150 ~240 ~280 ~450 ~600
Motor Power(kw) 0.75x2 2.2 x2 3.7 x2 5.5 x2 7.5 x2 8.5 x2
Installation angle(0 ) 5 5 5 5 5 5
Funnel Size (mm) 600x1600 960x3600 1100x3800 1200x4200 1300x4900 1500x6000

Overall dimension(mm) 1800x850X1200 3850x1950X1630 4400x2050X1660 4500x2050X1700 5200x2350X1750 6280x2350X2400
