Brand: jinansenfeng
Model: sf1325
Min. Order: 1
Laser Marking Machine
Laser Cutting Machine
Laser Engraving, Machine
SF1325-II
Characteristics:

★Fast speed, high efficiency, the idle speed can reach 32m/min.

In the engraving of the wave board the speed can reach over 20m/min.

★Big bearing redundancy, long life. The equipment adopts square and strait line contrail ,the contact is face to face. To the high CNC data control equipment, the lifetime of the strait line is 2200 times the common ones.

★The power of the main axis is big, the steel is of high quality. The main axis is suitable for the engraving on the copper, aluminum, iron. It is most suitable for the engraving of wood.

★Double engine drive, special double gear running, the strength is big, the running is stable, guarantee it to run without distortion and totter.

★All through offline running function: At the working process, all the system can run by itself and need no computer.

Specifications:

● size: SF1325

●table size: 1350×2550mm

●working area: 1300×2500m

●resolution ratio: 0.025mm

●Main power: 1.2KV

●Working voltage: AC220V/50Hz

●Running speed: 0-32m/min

●The speed of the main axis: 24000 revolution/min

●Feeding height: 100mm

●The diameter of the knife: Φ3.175, Φ6

●Engraving code: HPGL、G code

Applicable area:

Applicable for advertisement, double face board and scutcheon, department brand, chest brand and the architecture board, ABS brand, the engraving and cutting of acrylic and the engraving of many jade article.
