Brand: Secure-Net
Model: 50*200
Price: USD 7.4-8.5 / unit
Min. Order: 200pcs unit
Airport Fence
Metal Fence
Security Fence
Secure-Net Airport Fence procuduct brief intruduction

High rigidity

The Secure-Net panel is made of low carbon wire and its diameters is 4-6mm with tightening folds according to the height of panel.

Easy & quick to erect

The tightening folds of the Secure-Net panel make the handling and erection easier. This panel perfectly suits all flat or uneven grounds, and can be either sealed into the ground or screwed on a low wall or pavement. It suits any height of the Secure-Net Fence range for a higher speed of erection.

High protection of sensitive sites & sports facilities

The Secure-Net panel is designed to secure sensitive areas, such as plants, train stations, airports, military sites, but also to protect sports facilities and leisure centres.

High protection against corrosion

Secure-Net Mesh is a welded mesh panel made of galvanised & powder-coated steel wires. The Long Life Technology powder-coating process guarantees a long life span and a reliable protection against corrosion.
——————————————————————————————————————————————————————————————————————————————
———————————————————————————————————————
Welded mesh fence Brief Introduction

Weldmesh Light - 25m Rolls - Galvanised
Fence Height m Mesh x Wire mm Weight kgs
0.9 50 x 50 x 2.50 35.8
1.2 50 x 50 x 2.50 47.3
1.4 50 x 50 x 2.50 55.0
1.5 50 x 50 x 2.50 58.9
1.8 50 x 50 x 2.50 70.5
2.1 50 x 50 x 2.50 82.0
2.4 50 x 50 x 2.50 93.6

Weldmesh Medium - 25 - 12.5*M Rolls - Galvanised
Fence Height m Mesh x Wire mm Weight Kgs
0.9 50 x 50 x 3.00 51.8
1.2 50 x 50 x 3.00 68.1
1.4 50 x 50 x 3.00 79.3
1.5 50 x 50 x 3.00 84.8
1.8 50 x 50 x 3.00 101.5
2.1 50 x 50 x 3.00 118.0
2.4 50 x 50 x 3.00 134.8
2.7* 50 x 50 x 3.00 75.8
3.0* 50 x 50 x 3.00 84.2

Weldmesh Heavy - 25 - 12.5*M Rolls - Galvanised
Fence Height m Mesh x Wire mm Weight Kgs
0.9 75 x 25 x 3.00 68.2
1.2 75 x 25 x 3.00 90.4
1.425 75 x 25 x 3.00 107.1
1.5 75 x 25 x 3.00 112.6
1.8 75 x 25 x 3.00 134.8
2.1 75 x 25 x 3.00 157.1
2.4 75 x 25 x 3.00 179.3
2.7* 75 x 25 x 3.00 100.8
3.0* 75 x 25 x 3.00 111.9

Weldmesh Medium - 25 - 12.5*M Rolls - PVC Coated Green
Fence Height m Mesh x Wire mm Weight Kgs
1.00 50 x 50 x 2.95/2.45 42.2
1.22 50 x 50 x 2.95/2.45 50.6
1.83 50 x 50 x 2.95/2.45 73.8
2.51* 50 x 50 x 2.95/2.45 102.9

Weldmesh Heavy - 25 - 12.5*M Rolls - PVC Coated Green
Fence Height m Mesh x Wire mm Weight Kgs
1.22 50 x 50 x 3.50/3.00 71.4
1.83 50 x 50 x 3.50/3.00 105.5
2.01 50 x 50 x 3.50/3.00 116.9
2.51* 50 x 50 x 3.50/3.00 117.3






Detailed Product Description
mesh fenceWelded Point Tensile Strength:3000-5000 NWire Tensile Strength:Mpa500-550 MpaMaterial :1008,Q195,Q235

mesh fence
--Without any screw and nut we install this fence in a way of push and pull then get a whole unremovable unite. Save your working time and cost
---Perfect surface treatment and quality guarantee
---10 years using time with our promise
---Saving lots of maintenance fee in the future and take up a good job of protecting the customers property.

Wire Diameter(mm) Mesh(Width/Height)(mm) Post Type(mm) Panel Width(M) Panel Height (M)
4/4 50×10050×200
55×10055×200
65×10065×200 70×100 2.0;2.5;3.0 0.6;0.8;1.0;1.2;1.4;1.6;1.8;2.0;2.2
50×70 2.0;2.5 0.6;0.8;1.0;1.2;1.4;1.6;1.8
5/4 50×10050×200
55×10055×200
65×10065×200 70×100 2.0;2.5;3.0 0.6;0.8;1.0;1.2;1.4;1.6;1.8;2.0;2.2
50×70 2.0;2.5 0.6;0.8;1.0;1.2;1.4;1.6;1.8
5/5 50×10050×200
55×10055×200
65×10065×200 70×100 2.0;2.5;3.0 0.6;0.8;1.0;1.2;1.4;1.6;1.8;2.0;2.2
50×70 2.0;2.5 0.6;0.8;1.0;1.2;1.4;1.6;1.8
6/5 50×10050×200
55×10055×200
65×10065×200 70×100 2.0;2.5;3.0 0.6;0.8;1.0;1.2;1.4;1.6;1.8;2.0;2.2
50×70 2.0;2.5 0.6;0.8;1.0;1.2;1.4;1.6;1.8
6/6 50×10050×200
55×10055×200
65×10065×200 70×100 2.0;2.5;3.0 0.6;0.8;1.0;1.2;1.4;1.6;1.8;2.0;2.2
50×70 2.0;2.5 0.6;0.8;1.0;1.2;1.4;1.6;1.8
