Stainless Steel Wire Mesh
Wetter offers better woven wire mesh and services. Typical Weaving Patterns as Follows:

Plain Weave Wire Mesh:
The warp wire that establish the length of the wire mesh and the weft wire, parallel to the width, cross one another, alternating one on the top and one under, forming a 90° angle between each other.
Solid woven wire mesh may have a square or rectangular opening.
Wire mesh clothes are basic components in the production of filters, colanders for aliments, chemicals products, shielding, mosquito nets, etc.

Wire Materials:
Stainless Steel Wire: Aisi 304, 304L, 316, 316L, 310, 314, 410, 430.
Special Steel: Cromax, Incoloy, Alloy Ni-Cr, Inconel, Nichel, Monel, Titanium, Duplex.
Woven wire mesh is also available with carbon steel, low carbon steel, galvanized steel, brass, bronze, copper, aluminum alloy, etc.

Tabby Plain Weave Wire Mesh Product Features:
Stainless steel wire mesh plain woven offers high filtering efficiency, low pressure loss, constant mesh opening, good dimensional stability, high open surface area and good fireproof property.
Technical Note:
1, Standard roll width of stainless steel wire mesh: 1m or 48"
2, Standard roll length of stainless steel wire mesh: 30m or 100'
3, Material of stainless steel wire mesh: AISI 304 or 316
Stainless steel wire mesh plain woven sizes:
2mesh/3mesh/4mesh/5mesh/6mesh/8mesh/10mesh/12mesh/14mesh/16mesh/
18mesh/20mesh/26mesh/30mesh/40mesh/50mesh/60mesh/70mesh/80mesh/ 90mesh/100mesh/120mesh/150mesh/160mesh/180mesh/200mesh/250mesh/ 300mesh/325mesh/350mesh/400mesh/

Twilled Woven Stainless Steel Wire Mesh
In the Twilled Woven Wire Mesh, the wires of the weft and the warp intercross two above and two below , inverting the intersections of the warp wire at an established distance, obtaining a rigid, stable and robust type of wire mesh fabric.
Crossed twilled wire mesh are basic components in the production of filters, colanders for aliments, chemicals products, shielding, mosquito nets, etc.
