Brand: SBKJ
Model: SBYH-1400
Min. Order: 1 set
Spiral Tubeformer
Spiral duct former
tuberformer
Type: SBYH-1400
Thickness: 0.6-1.0mm
Tube diameter: 150-1400mm(making small diameter without middle axes of the cutting system)
Tube length:100-8000mm
Mainmotor Power: 11KW
Weight: 2500KG
Feeding speed:1-35m/min
Hydraulic motor power:4KW
Pump motor power:125W
Transport motor power:125W
Cutting system:cutting goes with rolling(no-noise,smooth cutting without burr)
Run-off system:hydraulic automatic run off (with 2 goods shelves,per length 3meters)
Forming roll system:Moulded(one mould go by one diameter)
