Brand: vipeak
Model: YGM85,95,130
Min. Order: 1
grinding mill
grinding machine
mill grinder
High Pressure Suspension Grinder Mills are used to grind barite, limestone, kaolin, ceramics
and slag, whose Moh's hardness is below 9.3 scales, non-inflammable and non-explosive material.

Features:
1) our patent product
2) Product size is adjustable in the range of 80 - 425 meshes
3) Better design which reduces cost

Models available:
1) YGM75 High Pressure Suspension Grinder Mill
a) Number of roller: 3
b) Diameter of roller: 260mm
c) Height of roller: 150mm
d) Inside diameter of ring: 780mm
e) Height of ring: 150mm
f) Max. feeding size: 15mm
g) Fineness of product: 0.613 - 0.033mm
h) Capacity: 0.28 - 3.0MT
2) YGM85 High Pressure Suspension Grinder Mill
a) Number of roller: 3
b) Diameter of roller: 270mm
c) Height of roller: 140mm
d) Inside diameter of ring: 830mm
e) Height of ring: 140mm
f) Max. feeding size: 20mm
g) Fineness of product: 0.613 - 0.033mm
h) Capacity: 0.35 - 3.4MT
i) Dimensions: 5,300 x 4,100 x 5,200mm
3) YGM95 High Pressure Suspension Grinder Mill
a) Number of roller: 4
b) Diameter of roller: 310mm
c) Height of roller: 170mm
d) Inside diameter of ring: 950mm
e) Height of ring: 170mm
f) Max. feeding size: 25mm
g) Fineness of product: 0.613 - 0.033mm
h) Capacity: 1.5-5MT
i) Dimension: 7,100 x 5,900 x 7,900mm
4) YGM130 High Pressure Suspension Grinder Mill
a) Number of roller: 5
b) Diameter of roller: 410mm
c) Height of roller: 210mm
d) Inside diameter of ring: 1280mm
e) Height of ring: 210mm
f) Max. feeding size: 30mm
g) Dimensions: 9,200 x 7,250 x 9,700mm
h) Capacity: 5-8MT
for more information information,please refer to our website: http://www.grinderpro.com/product.html
