Brand: TKM
Model: s-22
Price: CNY 7 / PC
Min. Order: 3000 PC
switches
Operating speed 0.01mm to 1m/sec.
Mechanically 240 operations/min.
Electrically 20 operations/min.
Contact resistance 15mmΩ
Insulation resistance 100MΩ(at 500VDC).
Dielectric strength 1,000 VAC, 50/60 Hz for 1 minute betweennon-contenuous terminals.
2,000 VAC, 50/60 Hz for 1 minute between current-carrying part and ground. Vibration Mechanical durability
10 to 55Hz 1.5mm double amplitude.
Shock
Mechanical durability Approx. 1,000m/ Sec²(about 100G'S).
Malfunction durability Approx. 3,00m/ Sec²(about 30G'S) .
Ambient operating temperature
General purpose type -25 to +80 Celsius.
Sealed type -15 to +80 Celsius.
Humidity
General purpose type 85% RH max.
Sealed type 95% RH.
Service life
Mechanically 20,000,000 operations min.
Electrically 500,000 operations min.
Weight Approx. 22 to 58g.
Type
1A-20A(125VAC-250VAC) BAKELITE
