Brand: ZN
Model: TY
Price: USD 2500 / 1
Min. Order: 1set 1
Turbine Oil Purifier
Oil Recycling
oil purification
Contact: Ms. Yolanda Lei
Mobile Phone: 0086 18725628355
Tel:0086 023 68681159
Fax:0086 023 68060921

Email:
yolanda86123@hotmail.com
yolanda86123@gmail.com
yolanda86123@yahoo.com
oilpurifier.yolanda@zhongnengcq.cn
Skype: yolanda86123

Website:
http://oil-recycle-sys.diytrade.com
http://yolanda86123.ec51.com
http://www.leizeyan.com
http://www.zhongnengcq.cn
Transformer Oil Purification Oil Purifier Oil Purification Used Oil Recycling Transformer Oil Dehydrator Lube Oil Purifier Hydraulic Oil Purification
Vacuum Oil Dehydration Turbine Oil Purification Insulating Oil Dehydrator

It is used for treating the unqualified turbine oil, especially the seriously emulsified turbine oil.

Application:
It is used for treating the unqualified turbine oil, especially the seriously emulsified turbine oil. This products, which can rapidly and effectively remove the water, gas and impurities, break emulsification. It aims at turbine oil’s nature of high water content, easy emulsifiable and high impurity content, and makes the oil recover the new oil's nature.

Feature:
1. Breaking emulsification thoroughly with high- molecule polymeric material.
2. Dewatering very effectively with once and for two steps dehydrating method. It can thoroughly clear away the liquid water, free water and 80% dissolved water.
3.With distinctive removing impurities technique filtering through double FH trapezoidal network and absorbing by high polymer material, this machine can make the ß3 equal or surpass 200 and make the cleanness lower grade 6(NAS1638).
4.With the trapezoidal, spiral, automatic back flushing system.
5.With the advanced dielectric condensation devices.
6.On-line oil purification can be carried out with turbine or water turbine automatically without any person.

Advantage:
This machine breaks emulsification thoroughly, and the oil is very difficult to emulsify again after treatment. Its dehydration volume is large and it can absorb water on line. TY series, which prevent lubrication system from damage, can effectively extend the lifetime of oil and protect turbine and other machines.


Table1 Technical Parameters
Item Unit TY-10 TY-20 TY-30 TY-50 TY-100 TY-150 TY-200
Flow rate L/min 10 20 30 50 100 150 200
Working vacuum degree MPa 0.06 ～ 0.095
Working pressure MPa ≤0.3
Running temperature ℃ 40 ～ 70（the temperature of turbomachine below 55℃）
Heating power kW 14 16 18 30 45 55 60
Total power kW 16 18 20 33 48 61 71
Inlet/outlet caliber mm φ25 φ25 φ25 φ32 φ42 φ50 φ50
Size L mm 1280 1350 1350 100 1500 1500 1600
W mm 750 900 950 950 1000 1200 1350
H mm 1450 1450 1500 1600 1650 1800 1800
Weight kg 320 400 420 450 750 800 900
Table2 Guarantee Data after Purification
Capability item Data
Moisture ≤100PPM
Break emulsification value ≤15min (GB/F 7305)
Clean degree ≤6grade (NAS1638)
