Brand: SHIBO
Model: tube -1400
Min. Order: 1pcs
GSL-1300 high temperature vacuum tube f
tube furnace
Characteristic: MOSI2 heating elements,
Out diameter of tube: 60, 80, 100mm
51paragraph programmable temperature control
Being able to introduce other atmosphere and vacuum-pumping


GSL-1300 high-temperature vacuum tube furnace takes SIC heating element as heating elements whose rating temperature is 1200C, and adopts S-type platinum-rhodium thermocouple to measure temperature and auto-control the temperature by 708 P-automatic temperature instrument. It has high precision in temperature control (+/-1 C).
In addition, the furnace with a vacuum device can work under a variety of atmosphere that greatly increasing the scope of its application. The furnace has the advantages of the use of high temperature, high-precision temperature control, simple operation, easy maintenance, and other advantages, which can be widely used in metallurgy, machinery, light industry, commodity inspection, institutions of higher learning and scientific research departments.


Model GSL-1300

Size φ60×1000mm
φ80×1000mm
φ100×1000mm
Heating elements SIC heating elements
Temperature =<1300C
Max temp 1400C
Temp control Intelligent programmable temp control
Temp accuracy +/-1C
Working voltage AC220V  50/60Hz
Rated power 4KW
Outside size  550×450×670mm
weight About 150kg
