Diamond Wire Mesh Mac
diamond mesh machine
rhombus mesh machine
Diamond Wire Mesh (Chain Link Fence) Machine

Semi-automatic chain link fence machine is easy for operation and control. The surface of the chain link fence is flat after being arranged. This machine has reliable property, less troubles and easy maintenance. It is suitable for small enterprises.


Main technical data:
1. Outside dimensions: Length: 2400mm, width: 4400mm, hight: 2500mm
2, Maximum working platform: 8000mm, maximum weaving width: 8000mm
3, Maximum weaving aperture: 52x52mm
4, Maximum wire diameter: 4.0mm, minimum wire diameter: 1.0mm
5, Power: 3KW/ set, 0.12KW/set
6, Productivity: 15-20 m2 /hour
7, Total weight: 1.5T.

Fully Automatic Diamond Wire Mesh (Chain Link Fence) Machine
Spider brand fully automatic chain link fence machine we produce is made with adaptation of Germany technology. This machine offers high productive efficiency and reliable quality chain link fence products with reasonable design, using computer control, mechanical and electrical integration, automatic control of wire feeding, cutting, rolling and edge treatment. Import advanced technology and domestic machinery prices make this machine an ideal choice for chain link fence producers.

Main Technical Data:
1. Capacity: (square meter/hour) 25-60
2, Steel wire diameter: (mm) Φ2.0—Φ4.0. Wire feeding number: double wires. Note: The steel wire meets the standard: GB3081-82 YB544-65 Steel Wire Material: B 1 F-B 3F
3, Chain link fence roll width: (mm) 600-2000, at any length
4, Power: electric motor: 3.0KW one set, 4.0KW one set, 0.12 KW one set.
