5A Molecular Sieve
Molecular Sieve
Chemical Formula：3/4CaO•1/4Na2O•Al2O3•2 SiO2•9/2H2O
Si/Al ratio：SiO2/ Al2O3≈2
Pore diameter：About 5A
Use：Gas separation and purification, such as alkane/ isomer, nitrogen/oxygen; desiccation.
Technical parameter：
Parameter Unit Bead Pellet
Size mm 1.6-2.5 3-5 1.6 3.2
Water adsorption capacity
（25℃,RH50%） ％wt ≥21 ≥21 ≥21 ≥21
Abrasion ％wt ≤0.2 ≤0.2 ≤0.25 ≤0.25
Bulk density g/ml ≥0.65 ≥0.65 ≥0.65 ≥0.65
Crush Strength N ≥28 ≥60 ≥30 ≥60
Water content（575℃,3h） ％wt ≤1.5 ≤1.5 ≤1.5 ≤1.5
n-hexane adsorption capacity mg/g ≥120 ≥120 ≥120 ≥120
Reactivation:
1、Removal of water: Hot gas at 200-350℃ and pressure 0.3-0.5㎏/㎝2 flows through the molecular sieve bed for 3-4 hours. let temperature decreases down to 110-180℃, cooling.
2、Removal of organics: Regeneration is achieved by means of steam treatment to remove organics, and then remove water with method 1.
