13X Molecular Sieve
Molecular Sieve
Chemical Formula：Na2O•Al2O3•（2.8±0.2）SiO2•（6-7）H2O
Si/Al ratio：SiO2/ Al2O3≈2.6-3.0
Pore diameter：About10A
Use：Desiccation and purification of air. Removal water and CO2 for in –flow in air-separation equipmengt. H2S and sulphide removal for hydrocarbons and natural gas. Catalyst support.
Technical parameter：
Parameter Unit Bead Pellet
Size mm 1.6-2.5 3-5 1.6 3.2
Water adsorption capacity
（25℃,RH50%） ％wt ≥25 ≥25 ≥25 ≥25
Abrasion ％wt ≤0.2 ≤0.2 ≤0.25 ≤0.25
Bulk density g/ml 0.62-0.67 ≥0.65 ≥0.65 ≥0.65
Crush Strength N ≥30 ≥60 ≥30 ≥60
Water content（575℃,3h） ％wt ≤1.5 ≤1.5 ≤1.5 ≤1.5
CO2 adsorption capacity
（25℃,250mmHg） ％wt ≥17.58 ≥17.58 ≥17.58 ≥17.58
Reactivation：
1、Removal of water: Hot gas at 200-350℃ and pressure 0.3-0.5㎏/㎝2 flows through the molecular sieve bed for 3-4 hours. let temperature decreases down to 110-180℃, cooling.
2、Removal of organics: Regeneration is achieved by means of steam treatment to remove organics, and then remove water with method 1.
