Brand: CJDS
Model: WSS
Price: CNY 10 / Sets
Min. Order: 100 Sets
With heat shrinkable
heatshrink
Pipeline corrosion
Shrink WSS sets (with) family of products for the underground and overhead steel pipe Welded Joints of the anti-corrosion and heat insulation pipelines designed to fill the mouth. It is by radiation crosslinking polyolefin substrate and specialty hot melt adhesive sealing compound formed, special sealed with hot melt adhesive polyolefin substrate, the surface of steel pipe and solid epoxy coating can form a good bond. WK-WSS shrinking with the installation of heating, the substrate in the radial contraction at the same time, internal composite layer melting, tightly covered in the meeting I Department, together with the matrix form in the pipeline corrosion has become a solid body with excellent wear resistance, corrosion resistance, impact resistance and good anti-aging properties of UV and optical.

Characteristics:
- High mechanical strength, anti-aging ability.
- Environmental stress-resistant performance.
- Adhesive performance.
- Easy to use.



Application Guide:

Implementation of standards
SY / T 0413-2002, NACE RP0303-2003

Maximum operating temperature
80 ℃

Applicable anti-corrosion coating
PE, FBE, PP

Steel pre-heating temperature
75 ℃

Recommended rating derusting
Sa 2.5

Product specifications
Products can be used for all the DN100-DN1000 steel pipe
Substrate thickness from 1.0-2.0mm, layer thickness from 0.8-2.0mm
技术参数 Technical Data

序号
测试项目Property 测试方法Test Method 检测结果Typical Value
基材

拉伸强度Tensile Strength GB/T1040-92 24N/mm2
断裂伸长率Ultimate Elongation GB/T1040-92 520%
介电强度 GB/1408.1-99 33MV/ m
体积电阻率 Volume Resistivity GB/T1410-89 4.0x1015Ω•m
吸水率Water Absorption ASTM D570-2005 0.02
热老化(150℃,21天) GB/T1040-92
拉伸强度 14.6 N/mm2

断裂伸长率% 300%
耐紫外线老化 EN12068
断裂伸长率% 480%
热熔胶
软化点℃ GB/T4507 123℃
热缩套

剥离强度 GB/T2792-98
对底漆钢 N/cm 140N/cm
对PEN/cm 95 N/cm

阴极剥离(60℃,30d,-1.5v)mm SY/T 0413-2002 18 mm
热水浸泡 ASTMD870-2002 在试验条件下没有分层、没

有水侵蚀痕迹
