Brand: SHIBO
Model: box -1600
Min. Order: 1pcs
BOX-1600 BOX FURNACE
box furnace
BOX-1600 Box Furnace uses MoSi2 heating element as heating element, adopting 50segments programme to control the temperature. Double-layer steel structure with air cooling system. And the top of furnace can be equipped vent. The chamber and control system is designed perfectly, and the chamber uses alumina fiber, saving energy, small volume, fast temperature ascending and descending, it is an excellent product for university, science research institution, mining industry to make powder, ceramic sinter and anneal.

Model Chamber size power (kw) voltage (V) Rated temp.C Max.temp C Eestimated Weight (kg)
depth (d) width (w) Height (H)
BOX1600-I 300 200 200 6 220 1550 1600 100
BOX1600-II 400 250 250 7 220 1550 1600 120
BOX1600-III 400 300 300 10 380 1550 1600 160
BOX1600-IV 500 400 400 16 380 1550 1600 200
