LED packaging tape / filling tape
LED packaging tape / filling tape

LED high temperature adhesive tape is soft polyester film as base material, single coated silicone pressure sensitive adhesive made of high performance. Has excellent heat resistance, no folds, no residual adhesive and solvent resistance, smooth face, etc., usually a length of 33M, width can be customized.

Name: LED Tape (high-temperature masking tape)

Total thickness mm: 0.09

Adhesion N/25mm: 8

Tensile strength N/25MM: 135

Elongation at break%: 60

Withstand voltage KV: 6

Temperature ℃: 180

Features / Use: solvent, temperature, mainly used in LED dot matrix block, the digital (LED), display sealing, filling in the LED's epoxy resin and high temperature curing process, the protective effect from the seal, there is clear or green easy to see the reflection of the debris cover. Product has good chemical resistance and weather resistance, peel no residue after use, do not leak, and the product of special matte surface effect products meet ROHS requirements of environmental protection.



Data for the measured data listed above, non-guaranteed value, for information!

Recommend the use of before trial, before a lot of use.
