Brand: SBECER/SBEC
Model: FC-230
Min. Order: 1pc
check weigher
weight checker
weight checking machine
【FEATURES】、
1.Advanced Hi Speed CPU.
2.LCD with Touch Screen.
3.Multi-Functional OS.
4.Based on DSP Technology.
5.Memory and Log.
6.HBM Load Cell.
7.New Designed Frame

【PURPOSE】
◆ Compact and intuitionistic screen operational interface.
◆ Auto-Statistic function turn weighing, maintenance, operation, statistic to more easier.

【SPECIFICATIONS】
▲ Model： FC-230
▲ Speed： 31-65m/min
▲ Belt Width： 230mm
▲ Alarm： Buzzer & Lamp
▲ Rejection： Air/Pusher/Stick
▲ Power： AC110V/220V 50-60HZ
▲ Rated Output： Appr.200W
▲ Dimension： 1468mm(L)*558mm(W)*1285±35mm(H)
▲ Weight： Appr.100Kg

【Sensitivity】
Weight Speed Accuracy
10-99g 70bags/min ±0.5g
100-199g 60bags/min ±0.5g
200-399g 50bags/min ±0.5g
400-999g 45bags/min ±1.0g
1000-5000g 40bags/min ±2.0g

▲ The specification is under standard test condition. The sensitivity depends on the
working condition. We have no responsibility that metal chips come out after detecting
under non-standard condition.
